Integrated low-power Celeron processor 3205U, 8 Gigabit Intel network cards, HDMI, 1 RJ45 serial port, 6 USB, GPIO, WatchDog
KANSUNG MINI PC
Integrated low-power Celeron 3205U Processor , 8 Gigabit Intel network cards, HDMI, 1 RJ45 serial port, 6 USB, GPIO , WatchDog
| Description | |
| CPU | Intel Broadwell SOC Processor, Celeron 3205U Dual Core 2M Cache, 1.5 GHz, 15W |
| Memory | Single Channel DDR3L 1333/1600MHz SDRAM, Max Support to 8G |
| Chipset | By CPU |
| Display | Intel HD Graphics |
| 1 x HDMI | |
| Ethernet | 8 x Intel Gigabit LAN |
| 1 x M.2 2230 for Wi-Fi Module | |
| 1 x Mini PCIE, Full-length for 3G/4G Module, Half-length for USB signal Wi-Fi Module | |
| Audio | N/A |
| Storage | 1 x mSATA for SSD，1 x SATA 3.0 |
| USB | 4 x USB 3.0，4 x USB 2.0 |
| Serial | 1 x RS-232 (Option Up to 6) |
| WatchDog | Yes |
| GPIO | Yes |
| RS-485 | 0 |
| Power On | Yes |
| Front I/O | |
| Power Button | 1 |
| Reset Button | 1 |
| LED | 1 x Power LED, 1 x HDD LED |
| DC-IN | 12V5A，5.5mm，2.5mm |
| Serial | 1 x RS-232 (RJ45) |
| USB | 2 x USB 3.0，4 x USB 2.0 |
| Display | 1 x HDMI |
| Rear I/O | |
| Ethernet | 8 x Intel Gigabit LAN |
| Other | |
| Material | Aluminum |
| Dimension | 217 x 122 x 62mm |
| Weight | 2.5kg |
| Packaging Dimension | 265 x 255 x 80mm |
| Kensington Lock | None |
| Cooling Mode | Fanless, passtive cooling |
| Mounting | VESA Mounting Bracket |
| OS Support | |
| OS | Windows 7，Windows 8，Windows10，Linux |
| Environmental | |
| Operting Temp | 0°C~50°C |
| Non-Operating Temp | -20°C~80°C |
| Humidity | 10%~90% |
| Packlist | |
| PackList | 1 x MiniPc，1 x Power supply，1 x Power cable，1 x VESA |
Remarks:
It can add extra 5 COM port for option, totally 6 COM port.
Packing list:
1 x Mini PC
1 x Power supply (12V 3A adapter and plug)
1 x VESA bracket
2 x Antennas (If you choose Wi-Fi)
Some screws for VESA and SATA
We have 2 kinds of packaging box, color box and neutral packaing. We use color box by default.
Five types Power Plug for optional
Nice + Strong + Safe Neutral Package
Black and Brown for Optional.
Different CPU for option
Different PC Case for option
Case S10
Dimension: 217 x 112 x 62 mm
Case S13
Dimension: 196 x 122 x 47 mm
